DIGITAL FILE Crawler G90 Sleeper Cab - 1/10 RC body

    • DIGITAL FILE Crawler G90 Sleeper Cab - 1/10 RC body

    PLEASE make sure your 3D printer is able to print a minimum size of 180x220x170mm before purchasing.


    The G90 Sleeper Cab is a stretched version of the G90 single cab which allows for more internal cabin space for those long journeys.

    It was mainly designed for use with longer wheelbase chassis, and will shine especially with a TRX6 with its 6x6 utilitarian nature.

    Trail ready chassis mounts are included for the VS4-10 Pro, SCX10 ii, SCX10 iii, TRX 4, TRX6, therefore any of these chassis will be a direct mount.

    As the design had the TRX6 in mind, the G90 Sleeper Cab will work very well with the G90 6x6 Expedition Suite (sold separately), with a wheelbase of 324mm from front to middle axle, and 454mm from middle to rear axle.

    Similar to the G90 Single Cab, the Sleeper Cab is ideally suited for 120mm diameter tyres, with outside tyre to tyre width of 220mm for best scale proportions. A wider and more aggressive stance of 240mm can also be used with the provided wider version fenders.


    Be sure to check out the instruction manual and gather all required hardware for assembly.


    *It is highly recommended to read the instruction manual before purchasing, to ensure you have all the required tools and hardware to assemble this body.*




    Assembly instructions:
    View the link below to download the assembly instructions
    https://www.aheadrc.com/manual

    .DXF files for all windows can be found here:
    https://www.aheadrc.com/dxf-files



    Should you need any help, please do not hesitate to contact us!

    • Included Options

      The G90 Sleeper Cab comes packed with features and includes scale accessories to match the look.

      • Stretched cabin with more window openings

      • Expedition long box scale accessory

      • Expedition medium box scale accessory

      • Expedition square box scale accessory

      • Square profile horn accessory

      • Round low profile horn scale accessory

      • Included optional roll cage, roof rack, and side ladders

      • LED Light buckets and lenses for roll cage roof

      • Cab top blinkers

      • Overland style front bumper with functional light buckets and lenses

      • Heavy duty style front bumper with function light buckets and lenses

      • Adjustable mirrors

      • Modeled dashboard, steering wheel, and wipers

      • Wide and standard width fenders (for 220mm and 240mm width)

      • All light buckets are functional (8x white 5mm LED, 6x orange 3mm LED)

    • Required Hardware

      • M2*5 Socket head x10
      • M2*8 Socket head x24
      • M2*10 Socket head x10
      • M3*5 Socket head x2
      • M3*10 Socket head x16
      • M3*12 Socket head x2
      • M3*15 Socket head x8
      • M3*20 Socket head x6
      • M3*10 Countersunk (CS) x3
      • M3*15 Countersunk (CS) x2
      • M3*3 Grub screw (GS) x4

    • Assembly Instructions

      Assembly Instructions

    • Printing Tips

      FDM printing:



      Requires a printer that can print a minimum volume of: 180x220x170mm.



      PETG filament

      0.2mm-0.3mm (0.4mm nozzle) layer heights

      20-30% infill density

      Supports are necessary

    • Finished and Assembled Size

      Finished and assembled size:

      328*218*177mm (All parts assembled excluding rear bumper and mirrors)

    • More pictures

      More pictures can be found here:

      More pictures

    HK$120.00Price
